1. Small size, lightweight and relatively compact structure, suitable for installation in ...
Gear Ratio: Customization
Rated Output Torque: 45NM
Max speed up Torque: 68NM
Instant Stop Torque: 102NM
Start Torque: <0.3NM
Life: 20000H
Max Radial Torque: 1500N
Max Axial Torque: 500N
Rated Input Speed: 3000r/min
Max Input Speed: 6000r/min
Work Temperature: -25+50℃
Protect Level: IP54
Backlash(arc-min): 20arc-min
Noise(30cm): <65dB
Full Loading Efficiency: 85%
Weight: 1.7kgs
Lubricating: Lifetime
Input and output rotation directions: Same
Logistics Sorting
Automated Robots
laser cutting
Access control gate
Photovoltaic Power Station
Medical Devices
AGV
1. Small size, light weight and relatively compact structure, suitable for installation in the AGV car.
2. High precision, high rigidity.less backlash and large torque, excellent positioning and rotation accuracy
3. Convenient to install, simple to operate, good versatility and long service life.
