1. Small size, lightweight and relatively compact structure, suitable for installation in ...
Gear Ratio: 7~10?
Rated Output Torque: 75NM
Max speed up Torque: 150NM
Instant Stop Torque: 190NM
Start Torque: 0.13NM
Life: 20000hour
Max Radial Torque: 700kgs
Max Axial Torque: 200kgs
Rated Input Speed: 3000rpm
MaxInput Speed: 4000rpm
Work Temperature: 25-40℃
Protect Level: IP54
Backlash(arc-min): 25arc-min
Noise(30cm): 63dB
Full Loading Efficiency: 88%
Weight: 5.3kgs
Lubricating: 263WL
Logistics Sorting
Automated Robots
laser cutting
Access control gate
Photovoltaic Power Station
Medical Devices
AGV
1. Small size, light weight and relatively compact structure, suitable for installation in the AGV car.
2. High precision, high rigidity.less backlash and large torque, excellent positioning and rotation accuracy
3. Convenient to install, simple to operate, good versatility and long service life.
